SCP Control Cable 4 Core For Slim Lutron Keypad, 2x 22AWG + 2x 18AWG LSZH, DCA Rated, Blue With Green Stripe Jacket: 305m
Details
SCP carries a complete line of composite cables for use with Lutron's various lighting and shade control systems. These include composite data or communications cables and composite data or control cables which are available in PVC rated CM and Low Smoke Zero Halogen (LSZH/LSOH) for commercial, marine and institutional applications.
SCP's CTRL-1-LSZH-B-G-UT is comparable to the Lutron's QS-CBL-LSZH. This cable is also a universal control system cable that can be used on various other brand's systems such as AMX® and Crestron®. Additionally, it can be used for systems control and instrumentation.
Now with a thinner 5mm outside diameter for simpler keypad connection.
This cable consists of 2 conductors 22 AWG insulated stranded bare copper twisted pair and shielded with overall aluminium foil low capacitance plus a 2 conductor 18 AWG insulated stranded bare copper twisted pair and unshielded, with a TC drain with an overall PVC jacket.
The cable includes SCP Cable Labelling System with sequential metre or foot markings and room, zone, outlet designations for easy cable identification.
UL listed, NEC: CM rated, CEC: CMG FT4, UL 13 and 444, NEC Article 725 and 800. EU RoHS, CECPR Euroclass Dca-s2,d1,a3. UL 1685 vertical tray.
This cable is also compatible with the AMX AXLink™ Systems.
Comes as a boxed 305m length.
