Lutron HomeWorks Universal DALI Power Module

The DALI Power Module unit from Lutron is a DALI-2 certified DIN rail mounted single master application controller for use with DALI compliant digital addressable loads in HomeWorks QSX systems. It provides DALI bus power and control for two independent DALI buses with up to 64 DALI compliant, digital addressable loads on each bus.

The Lutron HomeWorks Universal DALI Power Module is DALI-2 certified by the Digital Illumination Interface Alliance® (DiiA®). In order to ensure compatibility with Lutron DALI controllers, the connected DALI LED drivers and fluorescent ballasts must be DALI-2 certified and marked.

In addition to compatibility, it is important to select high quality and high performance LED drivers and fluorescent ballasts. DALI-2 certified devices are readily available from many manufacturers and are tested for compatibility with the standard. For a complete list of available DALI-2 certified devices, see the DiiA® website at https://www.digitalilluminationinterface.org/products. DALI devices that are not listed on the DiiA® website and are not marked DALI-2® cannot be considered DALI-2® certified.

The DALI version 1 standard does not ensure compatibility. To apply the original DALIversion 1 mark on LED drivers and fluorescent ballasts, no verification of the test results was required and manufacturers could self declare compliance and apply the DALI mark

If you would like to use an LED driver or fluorescent ballast that is not DALI-2 certified but carries a DALI version 1 logo, Lutron recommends that these devices be tested to ensure compatibility. Lutron is able to perform this testing on request. Samples of the drivers and light engines must be submitted to Lutron and the expected turnaround time is 6 to 8 weeks after the drivers are received. Fees for testing may apply.

Lutron recommends that this testing be performed before the fixtures and lighting controls are purchased and installed. Please contact the Team at Habitech on 01256 638500 for more information.
